Aatir Steel, based in Cairo, Egypt, is a reliable supplier and manufacturer of top-notch steel products, providing innovative solutions like WELDOX 700E Sheets and Plates. This structural steel is crafted to meet the highest standards of strength and weldability, making it perfect for applications where minimizing weight while maximizing load-bearing capacity is essential. Aatir Steel is committed to delivering consistent quality, fast delivery, and expert technical support across various sectors, including construction, heavy machinery, and transportation. With a strong emphasis on innovation and customer satisfaction, Aatir Steel has established itself as a vital partner for challenging steel projects throughout Egypt and the surrounding region.
WELDOX 700E is a robust structural steel that’s been quenched and tempered to deliver outstanding mechanical properties. Its chemical makeup features carefully controlled amounts of carbon, manganese, chromium, nickel, and molybdenum, all working together to boost strength and toughness. With a minimum yield strength of 700 MPa and a tensile strength ranging from 780 to 930 MPa, it also boasts impressive impact resistance, even in frigid conditions (tested down to -40°C). The “E” in its name signifies guaranteed toughness. Remarkably, WELDOX 700E still offers good weldability and formability, making it perfect for applications that need high load capacity while keeping plate thickness to a minimum.
Grade : 700E
Item : WELDOX 700E Sheets and plates
Thickness : 5 – 160mm, 6 – 60mm, 5 – 160mm
Width : 1000mm-4500mm
Length : 3000mm -18000mm
| C | Si | Mn | P | S | Cu | Ni | Cr | Mo | B |
| 0.20 max % | 0.60 max % | 1.60 max % | 0.020 max % | 0.010 max % | 0.30 max % | 2.0 max % | 0.70 max % | 0.70 max % | 0.005 max % |
| Thickness mm | Yield strength Rp 0.2, min MPa | Tensile strength RmMPa | Elongation A5 min % | Typical hardness HBW |
| 4 – 53 | 700 | 780 – 930 | 14 | 260 – 310 |
| (53) – 100 | 650 | 780 – 930 | 14 | 260 – 310 |
| (100) – 160 | 650 | 710 – 900 | 14 | 240 – 290 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
WELDOX 700E Sheets and Plates find their way into various industries that require both high structural strength and lighter weight. You’ll see it in action in mobile cranes, truck chassis, heavy trailers, lifting equipment, bridge structures, and offshore platforms. Thanks to its excellent strength-to-weight ratio, it allows for lighter yet stronger components, which in turn enhances fuel efficiency and load capacity in transport and construction machinery. This steel is also a great choice for high-rise buildings, pressure vessels, and welded structures that need to withstand tough conditions. Its dependable performance, ease of fabrication, and ability to cut down on overall structural weight make it a go-to material in modern engineering and industrial projects.
Aatir Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Cairo, Egypt.
