Aatir Steel, a well-respected manufacturer and supplier located in Cairo, Egypt, is known for its top-notch SA 516 GR.65N NACE HIC Plates, crafted to meet the highest industry standards. These plates are specifically designed for environments that are susceptible to hydrogen-induced cracking, ensuring they deliver outstanding reliability and safety. Aatir Steel is committed to rigorous quality control and precision manufacturing, resulting in plates that boast superior toughness, weldability, and corrosion resistance. Their SA 516 GR.65N NACE HIC Plates are trusted across Egypt and in international markets, especially in the oil, gas, and petrochemical industries for critical pressure vessel applications.
The SA 516 GR.65N NACE HIC Plates are primarily made up of carbon, manganese, silicon, phosphorus, and sulfur, along with carefully controlled micro-alloying elements that boost strength and corrosion resistance. These plates have a minimum yield strength of 240 MPa and a tensile strength ranging from 450 to 585 MPa. The “N” signifies normalization, which refines the grain structure and enhances toughness. Their remarkable resistance to hydrogen-induced cracking (HIC) and sulfide stress corrosion guarantees reliable performance even in harsh, corrosive environments.
| Grade | ASME SA 516 GR.65N Boiler and Pressure Vessel Steel Plates |
|---|---|
| Width | 1000mm-4500mm |
| Thickness | 5mm-150mm |
| Length | 3000mm-18000mm |
| Supply Condition | As Rolled, Normalized Rolling, Furnace Normalizing, Vacuum Degassing, Simulated Post-Weld Heat Treatment or as per customer requirement. |
| Impact tested | 52° C |
| Tempering | Notch toughness can be improved by quenched cooling from hot rolling or normalizing by the supplier. If such a faster cooling rate is agreed upon between purchaser and supplier then the steel is also to be tempered at 1200 F. |
| Applications | Used for weld fabrication of pressure vessels that require improved notch toughness for lower than ambient temperature service. |
| Process of Manufacturing | Hot-Rolled (HR) |
| C | Si | Mn | P | S | Al | Cr | Cu | Ni | Mo | Nb | Ti | V |
| 0.08/0.20 | 0.4 | 0.9/1.5 | 0.03 | 0.03 | 0.02 | 0.3 | 0.3 | 0.3 | 0.08 | 0.01 | 0.03 | 0.02 |
| Tensile strength (ksi) | Tensile strength (MPa) | Yield strength (ksi) | Yield strength (MPa) | Elongation in 200mm (min)(%) | Elongation in 50mm (min) (%) |
| 65-85 | 450-585 | 35 | 240 | 19 | 23 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| British Standard | European Norm | ASTM/ASME | DIN |
| BS1501-224-460A/B | EN10028 P295GH | A/SA516 – Grade 65 | DIN 17155 17 MN 4 |
Jaxon Steel is a trusted manufacturer and supplier of high-quality SA 516 GR.65N NACE HIC Plates in Cairo, Egypt. We specialize in premium steel products, including Alloy Steel, Carbon Steel, Mild Steel and Galvanized Steel, with a strong focus on Carbon Steel Sheet and Plates. Our extensive inventory also includes Pipes, Tubes, Flanges, Forged Fittings and Bars. Committed to fast delivery and exceptional customer service, we use only the finest raw materials to ensure superior strength, durability and performance for critical industrial applications. Contact us today for all your SA 516 GR.65N NACE HIC Plates needs!
Aatir Steel’s SA 516 GR.65N NACE HIC Plates are widely utilized in the construction of pressure vessels, boilers, storage tanks, and heat exchangers within the oil, gas, and petrochemical sectors. They are particularly well-suited for sour service environments where exposure to hydrogen sulfide is a concern. These plates provide exceptional resistance to cracking and pitting, which enhances safety and durability in critical operations. Moreover, they find applications in refineries, offshore platforms, and chemical processing plants, where high mechanical strength, corrosion resistance, and toughness are vital for maintaining performance under extreme conditions.
Aatir Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Cairo, Egypt.
