Aatir Steel stands out as a top-notch manufacturer and supplier located in Cairo, Egypt, specializing in high-quality SA 515 Grade 60 Sheets and Plates. These plates are crafted to excel in high-temperature pressure vessel applications. With cutting-edge technology and rigorous quality controls in place, Aatir Steel guarantees that every product boasts consistent mechanical strength, precise dimensions, and impressive durability. The company serves a variety of industrial sectors, including petrochemical, power generation, and construction, delivering dependable steel solutions that adhere to international standards and perform exceptionally well in tough operating conditions.
The SA 515 Grade 60 Sheets and Plates are primarily made up of carbon, manganese, phosphorus, sulfur, and silicon. This blend gives them remarkable strength, ductility, and resistance to oxidation at high temperatures. They feature a minimum tensile strength ranging from 415 to 550 MPa and a yield strength of about 260 MPa, making them perfect for both moderate and high-temperature service conditions. Their fine grain structure ensures outstanding toughness, weldability, and thermal stability, which are crucial for the fabrication of boilers and pressure vessels.
| Specifications | ASTM A515 Gr. 60 / ASME A515 Grade 60 | |
| Thickness |
|
|
| Length | 3000 mm – 8000 mm | |
| Width | 1500-3500mm | |
| Form | Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Strip, Flats, Blank (Circle), Ring (Flange) | |
| Finish | Cold rolled sheet (CR), Hot rolled plate (HR) | |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C | Mn | P | S | Si |
|---|---|---|---|---|---|
| A515 Grade 60 | 0.24-0.31 | 0.98 max | 0.035 max | 0.035 max | 0.13-0.45 |
| Grade | Thickness | Yield | Tensile | Elongation |
|---|---|---|---|---|
| A515 Grade 60 | 50-200mm | MPa -220 min | MPa – 415-550 | 21-25% |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
These sheets and plates are commonly utilized in the production of pressure vessels, boilers, heat exchangers, and industrial tanks. They shine in applications that involve moderate to high-temperature operations, such as those found in refineries, chemical processing plants, and power generation facilities. The plates perform exceptionally well under thermal stress and pressure, ensuring safety and reliability in demanding environments. Their excellent weldability and formability make them ideal for complex fabrication, providing a long service life and high structural integrity in various industrial and mechanical applications.
Aatir Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Cairo, Egypt.
