Aatir Steel is a reputable manufacturer and supplier located in Cairo, Egypt, focusing on top-notch S500MC Sheets and Plates. These high-strength, low-alloy steels are crafted for applications that demand exceptional mechanical performance, outstanding formability, and excellent weldability. With a commitment to precision and using cutting-edge production techniques, Aatir Steel guarantees that every product adheres to international quality standards. Renowned for their reliability, durability, and precise dimensions, the S500MC Sheets and Plates from Aatir Steel are extensively utilized in the automotive, construction, transport, and machinery industries to boost structural efficiency while minimizing weight without sacrificing strength.
The S500MC Sheets and Plates are made from micro-alloyed steel, incorporating elements like carbon, manganese, niobium, titanium, and vanadium, which enhance their strength and toughness. This material boasts a minimum yield strength of 500 MPa, excellent cold-forming capabilities, and impressive fatigue resistance. Additionally, it offers good weldability and a smooth surface finish, making it perfect for applications that require high performance and precision. The fine-grained structure of the steel ensures improved mechanical consistency and durability under dynamic loads.
| Item | High Tensile Steel Plate – EN 10149-2 / WNR. 1.0984 |
|---|---|
| Standard | ASTM, ASME and API |
| Size | 0.5 mm – 200 mm |
| Thickness range | 2.4mm-16mm |
| Width range | 900mm-1850mm |
| Length | 2000mm to 12000mm |
| Process of Manufacturing | Hot-Rolled (HR) |
| Hardness | Soft, Hard, Half Hard, Quarter Hard, Spring Hard etc. |
| Grade | C max | Si max | Mn max | P max | S max | AL max | Nb max | V max | Ti max |
| S500MC | 0.12 | 0.50 | 1.7 | 0.025 | 0.015 | 0.015 | 0.09 | 0.2 | 0.15 |
| Grade | ReH-Minimun yield strength(Mpa) | Rm-Tensile strength(Mpa) | Nominal thickness(mm) | A-Minimum elongation Lo=5,65√So(%) | Nominal thickness(mm) | A-Minimum elongation Lo=Lo=80mm(%) |
| EN 10149-2 S500MC | 500 | 550-700 | From3 | 14 | to3 | 12 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
In the automotive sector, S500MC Sheets and Plates are commonly used for chassis components, frames, and suspension systems where the strength-to-weight ratio is crucial. They also find applications in construction equipment, cranes, trailers, and load-bearing structures that need high strength and excellent formability. Their superior weldability and fatigue resistance make them ideal for manufacturing parts that face repetitive stress and dynamic loads. Thanks to these remarkable properties, S500MC plates deliver enhanced performance, durability, and cost-effectiveness in demanding structural and mechanical engineering applications.
