Aatir Steel is a reputable manufacturer and supplier located in Cairo, Egypt, focusing on Low Temperature Carbon Steel A333 Gr 1 Pipes that are engineered for outstanding performance in cryogenic and sub-zero temperature settings. These pipes are crafted to comply with ASTM A333 standards, guaranteeing exceptional mechanical strength, ductility, and reliability. Thanks to meticulous engineering and rigorous quality control, Aatir Steel provides pipes that excel in weldability and toughness. The A333 Gr 1 pipes find extensive application in the oil and gas, petrochemical, power generation, and LNG sectors, where durability and resistance to low temperatures are essential for safe and efficient operations.
The Low Temperature Carbon Steel A333 Gr 1 Pipes are primarily made up of carbon, manganese, phosphorus, sulfur, and silicon, creating a well-balanced mix of strength and toughness. They boast a minimum tensile strength of 415 MPa and a yield strength of 240 MPa, along with impressive elongation and impact resistance. These attributes make them perfect for low-temperature environments, offering excellent weldability, ductility, and resistance to brittle fracture. Their chemical and mechanical properties ensure dependable performance in challenging cryogenic service conditions.
| Type | Seamless / SAW / ERW / Spiral weld / Fabricated / Welded |
|---|---|
| Grade | Low Temperature Seamless Pipe: ASTM A333 Gr. 1 |
| Outer Dimensions | 19.05mm-457mm |
| Wall Thickness | 2.0mm-60mm |
| Lengths | required shall be specified on order.If no definite lengths required, following practice applies: |
| Single Random | 17′ ~ 24′ lengths |
| Double Random | 36′ ~ 44′ lengths |
| Additional Testing | NACE MR0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, etc. |
| Compositions | Data |
|---|---|
| Carbon(max.) | 0.30 |
| Manganese | 0.40–1.06 |
| Phosphorus(max.) | 0.025 |
| Sulfur(max.) | 0.025 |
| Silicon | … |
| Nickel | … |
| Chromium | … |
| Other Elements | … |
| Properties | Data |
|---|---|
| Yield strength(min) | 205Mpa |
| Tensile strength(min) | 380Mpa |
| Elongation(%) | 35 |
| Nominal | OD mm | Pipe size | Sch. 30 | Sch20 | Schedule 40 | Sch.STD | Sch 60 | Strong (XS) | Schedule Extra | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Mm | Inch | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wall | Wt. | Wt. | Wall | |
| 3 | 10.3 | 1/8 | 1.73 | 0.357 | 1.73 | 0.37 | 0.47 | 2.41 | ||||||
| 6 | 13.7 | ¼ | 2.24 | 0.625 | 2.24 | 0.63 | 0.804 | 3.02 | ||||||
| 10 | 17.1 | 3/8 | 2.31 | 0.84 | 2.31 | 0.84 | 1.1 | 3.2 | ||||||
| 15 | 21.3 | ½ | 2.77 | 1.26 | 2.77 | 1.26 | 1.62 | 3.73 | ||||||
| 20 | 26.7 | ¾ | 2.87 | 1.68 | 2.87 | 1.69 | 2.2 | 3.91 | ||||||
| 25 | 33.4 | 1 | 3.38 | 2.5 | 3.38 | 2.5 | 3.24 | 4.55 | ||||||
| 32 | 42.2 | 11/4 | 3.56 | 3.38 | 3.56 | 3.39 | 4.47 | 4.85 | ||||||
| 40 | 48.3 | 11/2 | 3.68 | 4.05 | 3.68 | 4.05 | 5.41 | 5.08 | ||||||
| 50 | 60.3 | 2 | 3.9 | 5.44 | 3.9 | 5.44 | 7.48 | 5.5 | ||||||
| 65 | 73 | 21/2 | 5.16 | 8.63 | 5.2 | 8.63 | 11.41 | 7 | ||||||
| 80 | 88.9 | 3/8 | 5.5 | 11.3 | 5.5 | 11.3 | 15.3 | 7.62 | ||||||
| 90 | 1.6 | 31/2 | 5.74 | 13.57 | 5.74 | 13.57 | 18.63 | 8.08 | ||||||
| 100 | 114.3 | 4 | 6.02 | 16.07 | 6.02 | 16.07 | 22.3 | 8.56 | ||||||
| 125 | 141.3 | 5 | 6.55 | 21.77 | 6.6 | 21.77 | 30.9 | 9.53 | ||||||
| 150 | 168.3 | 6 | 7.11 | 28.26 | 7.11 | 28.26 | 42.5 | 10.97 | ||||||
| 200 | 219.1 | 8 | 7 | 36.8 | 6.35 | 33.3 | 8.2 | 42.5 | 8.2 | 42.5 | 10.3 | 53.1 | 64.6 | 12.7 |
| 250 | 273 | 10 | 7.8 | 51.3 | 6.35 | 41.7 | 9.27 | 60.3 | 9.27 | 60.3 | 12.7 | 81.5 | 81.5 | 12.7 |
| 300 | 323.9 | 12 | 8.4 | 65.2 | 6.35 | 49.7 | 10.3 | 79.7 | 9.53 | 73.8 | 14.3 | 109 | 97.4 | 12.7 |
| 350 | 355.6 | 14 | 9.53 | 81.3 | 7.92 | 68.1 | 11.13 | 94.3 | 9.53 | 81.3 | 15.1 | 126.4 | 107 | 12.7 |
| 400 | 406.4 | 16 | 9.5 | 93.3 | 7.92 | 77.9 | 12.7 | 123 | 9.53 | 93.3 | 16.7 | 160 | 123 | 12.7 |
| 450 | 457.2 | 18 | 11.1 | 122 | 7.92 | 87.8 | 14.3 | 156 | 9.53 | 105 | 19 | 206 | 130 | 12.7 |
| 500 | 508 | 20 | 12.7 | 155.1 | 9.53 | 117.2 | 15.1 | 183 | 9.53 | 177.2 | 20.6 | 248 | 155.1 | 12.7 |
| 550 | 558.8 | 22 | 12.7 | 171 | 9.53 | 129 | 9.53 | 129 | 22.2 | 294 | 171 | 12.7 | ||
| 600 | 609.6 | 24 | 14.3 | 210 | 9.53 | 141 | 17.4 | 255 | 9.53 | 141 | 24.5 | 355 | 187 | 12.7 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aatir Steel is a leading supplier of high-quality Low Temperature Carbon Steel A333 Gr 1 Pipe products in Cairo, Egypt. We focus on steel solutions and offer a variety of products. This includes Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our products are Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. We are known for our good delivery and excellent customer care. We aim to provide strong and durable steel materials for many industrial uses. We work hard to meet high standards, making us a trusted partner for your steel needs.
These Low Temperature Carbon Steel A333 Gr 1 Pipes are widely utilized in industries that demand top-notch performance in low-temperature and high-pressure situations. They are particularly suited for LNG transportation, natural gas processing, petrochemical facilities, refrigeration systems, and power generation. Moreover, they are employed in pressure vessels, heat exchangers, and cryogenic storage systems. Their capability to retain strength and toughness in extreme cold ensures long-lasting durability and safety, making them a go-to choice for low-temperature fluid and gas transportation systems.
Aatir Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Cairo, Egypt.
