Aatir Steel, located in Cairo, Egypt, stands out as a top manufacturer and supplier of high-quality Carbon Steel SA179 Tubing. Known for its precision engineering and commitment to international standards, the company provides tubing that guarantees durability, reliability, and outstanding performance for even the most demanding industrial applications. Catering to industries like power generation, chemical processing, and mechanical sectors, Aatir Steel merges cutting-edge production methods with rigorous quality control to deliver products that meet essential operational and safety standards. Their SA179 tubing is celebrated for its excellent corrosion resistance, long lifespan, and seamless fit into intricate piping and mechanical systems.
The SA179 pipe provides a minimum tension strength of 325 MPa (47,000 PSI) and minimum return on 180 MPa (26,000 PSI). It provides a high increase (%35%) and better cruelty, making it ideal for heat exchange, capacitor and boiler applications. The spontaneous construction ensures high temperature and efficiency in the pressure environment.
| Grade: | ASME/ASTM SA179, SA192, SA210, SA178, SA214, API 5L |
|---|---|
| Size: | 1/8” NB TO 24” NB Sch 40/80/160/XXS |
| Form | Round, Square, Rectangular, Coil, U Tube, |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Bevelled End |
| Type | Seamless / ERW / Welded |
| Certification For Carbon | Mill Test Certificate as per EN 10204 / 3.2B |
| General Requirements | ASTM A 530/A 530M |
| Dimensional Tolerances | ANSI B 36.10 |
| OD Range | 1.250″ – 6.000″ (30-150mm) |
| Wall Range | 0.095″ – 1.000″ (.2.5-25mm) |
| Carbon | Silicon | Manganese | Phosphorous | Sulphur | Molybdenum | Nickel | Chromium | Copper | Others |
|---|---|---|---|---|---|---|---|---|---|
| 0.10-0.20 | max 0.25 | 0.30-0.80 | 0.035 | 0.035 | – | – | – | – | – |
| Yield Strength | Tensile Strength | Elongation A5 min | |||
|---|---|---|---|---|---|
| MPa min | ksi min | MPa min | MPa min | ksi min | Percentage |
| 324 | – | 47 | 35 | ||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
The Carbon Steel SA179 Tubing is mainly made up of carbon, manganese, phosphorus, sulfur, and a few trace elements that boost its mechanical strength, toughness, and durability. This tubing showcases impressive tensile strength, remarkable impact resistance, and adequate hardness, making it perfect for moderate-pressure and high-temperature scenarios. It maintains its shape well, resists deformation, and offers superior weldability and machinability. Produced in line with ASTM standards, SA179 tubing guarantees consistent mechanical properties, dependable performance, and long-lasting safety in industrial settings.
|
OD (mm) |
WT (mm) |
OD (mm) |
WT (mm) |
OD (mm) |
WT (mm) |
| 6.35 | 0.91 | 19.05 | 3.404 | 31.75 | 2.769 |
| 9.53 | 1.22 | 20 | 2 | 31.75 | 3.7 |
| 12.7 | 1.22 | 20 | 2.2 | 32 X 22 | 3.404 |
| 12.7 | 1.245 | 25 | 2 | 36 X 14 | 1.8 |
| 12.7 | 1.65 | 25 | 2.77 | 38 | 2.77 |
| 15.875 | 1.245 | 25.4 | 1.6 | 38 | 3.2 |
| 15.875 | 1.65 | 25.4 | 1.651 | 38.1 | 2.41 |
| 15.875 | 1.651 | 25.4 | 2 | 38.1 | 2.769 |
| 15.875 | 2.108 | 25.4 | 2.108 | 38.1 | 2.9 |
| 15.875 | 2.413 | 25.4 | 2.11 | 38.1 | 3.05 |
| 15.88 | 1.65 | 25.4 | 2.41 | 38.1 | 3.403 |
| 16 | 1.2 | 25.4 | 2.7 | 40 | 1.5 |
| 16 | 2 | 25.4 | 2.76 | 44.45 | 2.1 |
| 19.05 | 1.22 | 25.4 | 2.769 | 50.8 | 2.413 |
| 19.05 | 1.651 | 25.4 | 2.77 | 50.8 | 3.05 |
| 19.05 | 2 | 25.4 | 3.048 | 50.8 | 3.404 |
| 19.05 | 2.1 | 25.4 | 3.15 | 57.15 | 3.048 |
| 19.05 | 2.108 | 25.4 | 3.4 | 60.3 | 2 |
| 19.05 | 2.11 | 31.75 | 2.108 | 63.5 | 3.76 |
| 19.05 | 2.64 | 31.75 | 2.11 | 63.5 | 8 |
| 19.05 | 2.769 |
You’ll find Carbon Steel SA179 Tubing commonly used in boilers, heat exchangers, condensers, pressure vessels, and mechanical systems that require robust tubular components. It’s frequently utilized in power plants, refineries, chemical processing facilities, and water treatment systems. This tubing enables efficient fluid transport, endures thermal and pressure stresses, and reduces the risk of leaks, ensuring optimal operational efficiency. With its durability, reliability, and consistent performance, SA179 tubing is the go-to choice for critical industrial infrastructure where long-term safety and efficiency are paramount.
