Aatir Steel, a prominent manufacturer and supplier located in Cairo, Egypt, is all about delivering top-notch Carbon Steel API X80 5L PSL 2 Pipes. These pipes are crafted to meet the rigorous standards of the oil and gas sector, boasting remarkable strength, durability, and the ability to withstand tough environments. Aatir Steel prides itself on excellence, utilizing cutting-edge production technology, meticulous quality control, and prompt delivery. Their API X80 5L PSL 2 pipes are well-known for their outstanding weldability, toughness, and performance even in high-pressure and high-temperature situations across various industries.
The Carbon Steel API X80 5L PSL 2 Pipes are primarily made up of carbon, manganese, phosphorus, sulfur, and microalloying elements like niobium, vanadium, and titanium. These components work together to boost strength and weldability. With a minimum yield strength of 555 MPa and tensile strength ranging from 625 to 825 MPa, these pipes offer excellent impact resistance, good ductility, and superior fracture toughness, making them perfect for demanding pipeline applications. Their chemical makeup and mechanical properties guarantee optimal performance in high-stress, high-pressure settings.
| Standard | BS, JIS, GB, DIN, ASTM, API |
| Sizes (Seamless) | 1/2″ NB – 60″ NB |
| Sizes (ERW) | 1/2″ NB – 24″ NB |
| Sizes (SAW) | 16″ NB – 100″ NB |
| Features | High Yield, High Temperature |
| Type | Seamless / Welded / ERW / LSAW / Line Pipe |
| Wall Thickness | Schedule 20 – Schedule XXS (heavier on request) up to 250 mm thk. |
| API 5L Grade | C(Max) | Mn(Max) | P(Max) | S(Max) | Si(Max) | V(Max) | Nb(Max) | Ti(Max) |
|---|---|---|---|---|---|---|---|---|
| X80 PSL2 | 0.22 | 1.30 | 0.025 | 0.015 | 0.45 | 0.05 | 0.05 | 0.04 |
| API 5L Grade | Yield Strength min (MPA) | Tensile Strength min (MPA) | Elongation min. (%1) |
|---|---|---|---|
| X80 PSL2 | 483 | 565 | F |
| API 5L Grade | Yield Strength min. (ksi) | Tensile Strength min. (ksi) | Yield to Tensile Ratio (max.) | Elongation min. %1 |
|---|---|---|---|---|
| A | 30 | 48 | 0.93 | 28 |
| B | 35 | 60 | 0.93 | 23 |
| X42 | 42 | 60 | 0.93 | 23 |
| X46 | 46 | 63 | 0.93 | 22 |
| X52 | 52 | 66 | 0.93 | 21 |
| X56 | 56 | 71 | 0.93 | 19 |
| X60 | 60 | 75 | 0.93 | 19 |
| X65 | 65 | 77 | 0.93 | 18 |
| X70 | 70 | 82 | 0.93 | 17 |
| X80 | 80 | 90 | 0.93 | 16 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
You’ll find Carbon Steel API X80 5L PSL 2 Pipes widely used in oil and gas transmission, offshore drilling, and long-distance pipeline systems for moving natural gas, crude oil, and petroleum products. They’re also a go-to choice for water supply networks, construction frameworks, and chemical processing plants, thanks to their strength and resistance to corrosion. These pipes are designed for high-strength, low-alloy applications that require exceptional performance in challenging terrains and climates. Their consistent quality and reliability make them a top pick for critical energy infrastructure projects around the globe.
Carbon Steel API X80 5L PSL 2 Pipes are often used in high-pressure pipeline systems. They are strong and last a long time. These pipes are important in the oil and gas industry. They transport crude oil, natural gas and refined products over long distances. They are also needed in petrochemical plants, power generation and water distribution systems. Here, being reliable and handling extreme conditions is very important. Plus, these pipes get used in infrastructure projects like bridges and other structures. They are easy to weld and can handle impacts well. They also resist damage, ensuring they work safely and effectively in tough industrial settings.
