Tanvir Nickel Alloys, based in Cairo, Egypt, stands out as a reliable manufacturer and supplier of Carbon Steel API 5L X70 Sheets and Plates, specifically engineered for high-strength and high-performance applications in pipelines and structures. These plates are essential in the oil, gas, and petrochemical industries, where durability, strength, and resistance to extreme conditions are paramount. Adhering to API 5L specifications, X70 sheets and plates are versatile enough for both onshore and offshore projects. Tanvir Nickel Alloys guarantees top-notch product quality through cutting-edge production methods, thorough testing, and compliance with international standards, providing dependable steel solutions for energy markets worldwide.
The composition of Carbon Steel API 5L X70 Sheets and Plates typically includes a mix of carbon, manganese, phosphorus, sulfur, and trace amounts of microalloying elements like niobium, vanadium, and titanium. This unique blend boosts their strength and enhances resistance to stress and corrosion. With a minimum yield strength of 485 MPa and a tensile strength ranging from 570 to 760 MPa, these plates are delivered in a hot-rolled state, with options for heat treatment such as normalizing and quenching if needed. Their toughness and weldability meet the stringent requirements of PSL 2, making them perfect for pipelines operating in tough environments.
| Standard | API |
|---|---|
| Specification | API 5L GR. X70 |
| Width | 1000mm – 3000mm |
| Thickness | 1mm – 300mm |
| Production | Hot-Rolled (HR) / Cold-Rolled (CR) |
| Grades | Material number | C max | Si max | Mn. mix | P max | S max |
|---|---|---|---|---|---|---|
| X70 | 1.8977 | 0.04-0.16 | 0.55 | 1.10-1.70 | 0.035 | 0.035 |
| Grade | Permissible yield point ratio | Yield Strength MPa(min) | Tensile Strength MPa | Elongation % (min) |
|---|---|---|---|---|
| X70 | ≤ 0.85 | 480 | 600 – 750 | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
API 5L X70 Sheets and Plates find extensive application in constructing high-pressure transmission pipelines, structural supports, offshore platforms, storage tanks, and large fabrication projects. Their impressive strength-to-weight ratio allows for thinner walls, leading to more cost-effective and efficient material usage without sacrificing safety. Additionally, these plates are suitable for sour service and low-temperature applications when appropriately treated.
Carbon Steel API 5L X70 Sheets and Plates utilized in applications of high-pressure pipelines for the most part in oil and gas, petrochemical, and power plant industries. Plates are vital in carrying crude oil, natural gas, and other liquids through a long distance with their higher strength, resistance against corrosion, and durability. These Plates are also used in offshore and structural applications. Where higher toughness is needed. Their high weldability makes them fit for fabrication under challenging conditions.
