Aatir Steel is a well-known manufacturer and supplier of ASTM A572 Gr 50 Sheets and Plates in Cairo, Egypt. We offer high-strength, low-alloy steel solutions for construction, bridges, heavy machinery, and structural purposes. Our ASTM A572 Gr 50 plates are highly weldable, long-lasting, and resistant to atmospheric corrosion, withstanding the test of time. With a focus on quality and accuracy, Aatir Steel provides consistent steel products that are up to industry standards, hence the go-to for better steel solutions in the Egypt.
ASTM A572 Gr 50 Plates and Sheets contain carbon, manganese, phosphorus, sulfur, silicon, vanadium, columbium, and copper, which make them stronger and corrosion-resistant. They possess a minimum yield point of 50 ksi (345 MPa) and tensile strength of 65 ksi (450 MPa), making them durable and tough. Benefits are high strength-to-weight ratio, good weldability, excellent atmospheric corrosion resistance, and low cost. These characteristics render them suitable for construction, bridges, heavy machinery, and structural use, providing lasting performance under extreme conditions.
| Specifications | : | ASME SA572 / ASTM A572 |
|---|---|---|
| Width | : | 1500-4020mm |
| Length | : | 3000-27000mm |
| Thickness | : | 8-300mm |
| Hardness | : | As per ASME A & NACE MR 175 |
| Impact tested | : | Impact tested -52° C |
| Finish | : | Hot rolled plate (HR), Cold rolled sheet (CR) |
| Grade | C | Mn | P | V | Ni | Co | S | Si |
| A572 Grade 50 | 0.23 | 1.35 | 0.04 | 0.06 | 0.015 | 0.05 | 0.05 | 0.4 |
| Grade | Thickness | Yield | Tensile | Elongation |
| A572 Grade 50 | 8mm-200mm | MPa -345 min | MPa – 450 | 18-21% |
| Grade | India IS | England BS | Sweden MNC | Belgium NBN | Europe EN | Russia GOST |
| A572 Grade 50 Plate | FE410WC | 43EE | SS14,14，01 | AE 295 DD | S275 J2G3 Fe430 D2 S275NL |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| GRADE | GAUGE (INCHES) | WIDTH (INCHES) | LENGTH (INCHES) |
| A572 | 0.1875 | 96 | 240/480 |
| A572 | 0.2500 | 60/96/120 | 240/480 |
| A572 | 0.3125 | 60/96/120 | 240/480 |
| A572 | 0.3750 | 60/96/120 | 240/480 |
| A572 | 0.5000 | 60/96/120 | 240/480 |
| A572 | 0.6250 | 60/96/120 | 240/480 |
| A572 | 0.7500 | 60/96/120 | 240/480 |
| A572 | 0.8750 | 60/96/120 | 240/480 |
| A572 | 1.0000 | 60/96/120 | 240/480 |
| A572 | 1.1250 | 60/96/120 | 240/480 |
| A572 | 1.2500 | 60/96/120 | 240/480 |
| A572 | 1.5000 | 60/96/120 | 240/480 |
| A572 | 1.7500 | 60/96/120 | 240/480 |
| A572 | 2.0000 | 60/96/120 | 240/480 |
| A572 | 2.2500 | 96 | 240/480 |
| A572 | 2.5000 | 96 | 240/480 |
| A572 | 2.7500 | 96 | 240/480 |
| A572 | 3.0000 | 96 | 240/480 |
| A572 | 3.2500 | 96 | 240 |
| A572 | 3.5000 | 96 | 240 |
| A572 | 3.7500 | 96 | 240 |
| A572 | 4.0000 | 96 | 240 |
| A572 | 5.0000 | 96 | 240 |
| A572 | 6.0000 | 96 | 240 |
ASTM A572 Gr 50 Plates and Sheets are found to be extensively used in construction, bridges, industrial equipment, and structural applications because of their high strength, durability, and weldability. These plates are well-suited for the fabrication of building frames, crane booms, heavy machinery, and offshore structures and provide top-notch resistance against impact and atmospheric conditions. Their excellent mechanical properties make them ideal for railcars, transmission towers, and highway components. With improved toughness and cost savings, ASTM A572 Gr 50 plates provide long-term performance in challenging conditions.
Aatir Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Cairo, Egypt.
