Aatir Steel, a prominent manufacturer and supplier located in Cairo, Egypt, is well-known for its top-notch Alloy Steel T22 Tubing, specifically crafted for high-temperature and high-pressure applications. These tubes are produced using cutting-edge technology and comply with international ASTM/ASME standards, ensuring they boast exceptional strength, corrosion resistance, and durability. Aatir Steel’s dedication to precision engineering, rigorous quality control, and customer satisfaction has established it as a reliable name in the steel industry. The company provides dependable and high-performance alloy steel tubing solutions to a variety of industrial sectors both in Egypt and around the globe.
Alloy Steel T22 Tubing is mainly made up of chromium (2.00–2.50%), molybdenum (0.87–1.13%), along with carbon, manganese, silicon, phosphorus, and sulfur. This unique blend gives it remarkable mechanical properties, such as high tensile strength, excellent creep resistance, and outstanding oxidation resistance at elevated temperatures. The tubing is not only easy to weld but also maintains its toughness and dimensional stability, making it perfect for high-temperature and high-pressure settings where long-lasting performance is essential.
| ASTM A213 T22 Specification & Standard | ASTM A213 T22, ASME SA213 T22 (with IBR Test Certificate) |
|---|---|
| SA 213 Gr T22 Specification | ASTM A213 & ASTM A209 BS/3059/ 90/ Part II/ 620 & 622 DIN/ 17175/ 13CrMo44 DIN/ 17175/ 10CrMo910 DIN/ 17175/ 15Mo3 |
| T22 Steel Tube Sch. & Swg. | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg., 3.6 mm Thk |
| A213 T22 Tubing Size | 6.35 mm OD to 101.6 mm OD |
| ASTM A213 T22 Pipe Thickness | 3-12mm |
| ASME SA213 T22 Material Origin | European, Japanese, Korean, US, Russian, Indian (Strictly No Chinese Material) |
| Craft | Cold rolled and Cold drawn |
| ASTM A213 T22 Tube Type | Seamless / ERW / Welded / Fabricated |
| ASTM A213 Grade T22 Tube available in Form of | Round, Square, Rectangular, Hydraulic Etc. |
| A213 T22 Tube Tolerance | Cold drawn pipe: +/-0.1mm Cold rolled pipe: +/-0.05mm |
| ASME SA213 Gr T22 Tube Length | Standard Double & In Cut length also. |
| ASME SA213 T22 Tube End | Plain End, Beveled End, Treaded |
| ASTM A213 T22 Additional Testing | NACE MR 0175, NACE TM0177, NACE TM0284, HIC TEST, SSC TEST, H2 SERVICE, IBR, etc. |
| Specialized in |
|
| ASME SA213 Gr T22 Tube Application & uses | Seamless Ferritic Alloy Steel Tube for High-Temperature Service |
| Grade | C≤ | Mn | P≤ | S≤ | Si≤ | Mo |
|---|---|---|---|---|---|---|
| SA213 T22 Composition | 0.05~0.15 | 0.30~0.60 | 0.025 | 0.025 | 0.50~1.0 | 0.80~1.13 |
| Grade | Tensile Strength, MPa | Yield Strength, MPa | Elongation, % | Hardness, HB |
|---|---|---|---|---|
| SA213 T22 Boiler Tube | 415 min | 205 min | 30 min | 163 max |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Outside Diameter | OD Tolerance | WT Tolerance | Ovality Tolerance | Cut Length Tolerance |
| OD≤ 12, 7 mm | ± 0, 13 mm | ± 15 % | – | + 3, 18 mm, – 0 mm |
| 12, 7 mm < OD ≤ 38, 1 mm | ± 0, 13 mm | ± 10 % | max, 1, 65 mm | + 3, 18 mm, – 0 mm |
| 38, 1 mm < OD ≤ 88, 9 mm | ± 0, 25 mm | ± 10 % | max, 2, 41 mm | + 4, 76 mm, – 0 mm |
Jaxon Steel is a leading manufacturer and distributor of high-quality Alloy Steel T22 Tubing in Cairo, Egypt. We provide premium steel materials and an extensive range of products, including Alloy Steel, Carbon Steel, Mild Steel, and Galvanized Steel. Our comprehensive inventory features Tubes, Pipes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Dedicated to timely delivery and exceptional customer service, we use only the finest raw materials to ensure outstanding performance in industrial applications with rigorous specifications. Contact us today for all your Alloy Steel T22 Tubing needs!
You’ll find Alloy Steel T22 Tubing widely utilized in industries like power generation, petrochemical, oil and gas, and boiler manufacturing. It’s particularly suited for superheaters, heat exchangers, pressure vessels, and steam pipelines that operate under intense heat and stress. Thanks to its impressive thermal stability and corrosion resistance, it’s a great fit for refineries, chemical plants, and industrial heating systems. Its blend of strength, durability, and resistance to thermal fatigue guarantees safe and efficient performance in demanding service conditions across various heavy-duty industrial applications.
Aatir Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Cairo, Egypt.
