Aatir Steel is a well-respected manufacturer and supplier of ABS DH36 Shipbuilding Steel Sheets and Plates, proudly based in Cairo, Egypt. The company focuses on crafting top-notch marine-grade steel materials that adhere to international classification standards. These plates are designed to endure the toughest marine conditions, providing exceptional strength, toughness, and resistance to corrosion. Aatir Steel makes sure that every ABS DH36 plate goes through rigorous quality checks to ensure long-lasting reliability for offshore and shipbuilding projects. With precise manufacturing and consistent performance, Aatir Steel’s ABS DH36 steel plates are the go-to choice for shipbuilders, naval engineers, and offshore structure manufacturers around the globe.
ABS DH36 Shipbuilding Steel Sheets and Plates are made up of Carbon (0.18% max), Manganese (0.90–1.60%), Silicon (0.10–0.50%), Phosphorus (0.035% max), and Sulfur (0.035% max), along with micro-alloying elements like Niobium, Vanadium, or Titanium to enhance strength. These plates boast remarkable mechanical properties, featuring a minimum yield strength of 355 MPa, tensile strength ranging from 490–620 MPa, and outstanding impact resistance even in low temperatures, making them perfect for critical structural applications in ship hulls and offshore platforms.
STANDARD: ASTM A131, ASME SA131
PLATES QUALITY: DH36 (Dead Soft Quality)
THICKNESS: 3/16″ – 4″, 4-60mm
WIDTH: 48″ – 120″, 2000 / 2500 / 3000mm
LENGTH: 96″ – 480″, 6000 / 8000 / 10000 / 12000 mm
| Grade DH36 | C | Si | Mn | P | S | V | Al | Cr | Cu | Mo | Nb | Ni | Ti |
| 0.180 | 0.1-0.5 | 0.90-1.6 | 0.035 | 0.035 | 0.05-0.10 | 0.015 | 0.200 | 0.350 | 0.080 | 0.02-0.05 | 0.400 | 0.020 |
| Grade | Re | Rm | Elongation | |
|---|---|---|---|---|
| A50mm | A200mm | |||
| MPa | MPa | % | % | |
| DH 36 | 355 | 490/620 | 22 | 19 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Aatir Steel is one of the most prominent manufacturers and suppliers of superior quality ABS DH36 Shipbuilding Steel Sheet and Plates in Cairo, Egypt. As experts in steel solutions, we supply a complete spectrum of products like Carbon Steel, Alloy Steel, Mild Steel, and Galvanized Steel. Our product range comprises Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets, and Plates. Known for our reliable delivery and first-rate customer service, we are committed to supplying high-quality steel materials that guarantee durability and excellent performance in numerous industrial applications.
| theoretical weight | Thickness (mm) | Thickness (mm) | theoretical weight | ||
|---|---|---|---|---|---|
| Kg/m2 | Kg/ft2 | Kg/m2 | Kg/ ft2 | ||
| 47.10 | 4.376 Kg/ft2 | 6 | 25 | 196.25 | 18.962 Kg/ ft2 |
| 54.95 | 5.105 Kg/ft2 | 7 | 26 | 204.10 | 20.420 Kg/ ft2 |
| 86.35 | 8.751 Kg/ft2 | 11 | 32 | 251.20 | 25.525 Kg/ ft2 |
| 172.70 | 16.044 Kg/ft2 | 22 | 50 | 392.50 | 36.464 Kg/ ft2 |
| 62.80 | 5.834 Kg/ft2 | 8 | 28 | 219.80 | 21.879 Kg/ ft2 |
| 157.00 | 14.586 Kg/ft2 | 20 | 48 mm | 376.80 | 35.006 Kg/ ft2 |
| 78.50 | 7.293 Kg/ft2 | 10 | 30 mm | 235.50 | 23.337 Kg/ ft2 |
| 94.20 | 10.21 Kg/ft2 | 12 | 34 mm | 266.90 | 26.254 Kg/ ft2 |
| 125.60 | 11.669 Kg/ft2 | 16 | 40 mm | 314.00 | 29.172 Kg/ ft2 |
| 141.30 | 13.127 Kg/ft2 | 18 | 45 mm | 353.25 | 32.818 Kg/ ft2 |
| 109.90 | 10.939 Kg/ft2 | 14 | 35 mm | 274.75 | 27.713 Kg/ ft2 |
| 188.40 | 18.232 Kg/ft2 | 24 | |||
| Max. width | Thickness |
|---|---|
| DH36 | From to up to |
| 1370 | 1.70 to 1.80 |
| 1280 | 1.60 to 1.70 |
| 1440 | 1.80 to 1.90 |
| 1520 | 1.90 to 2.00 |
| 1170 | 1.49 to 1.60 |
| 2070 | 12.70 to 20.00 |
| 1590 | 2.00 to 2.20 |
| 1730 | 2.20 to 2.40 |
| 1880 | 2.60 to 2.80 |
| 1960 | 2.80 to 3.12 |
| 1800 | 2.40 to 2.60 |
| 2070 | 3.12 to 12.70 |
ABS DH36 Shipbuilding Steel Sheets and Plates are extensively utilized in building ships, offshore oil rigs, hull structures, deck sections, and marine equipment. Their excellent weldability, high tensile strength, and corrosion resistance make them suitable for both fresh and seawater environments. These plates perform exceptionally well under extreme loads and pressures, ensuring the safety and durability of marine vessels and offshore structures. Aatir Steel’s ABS DH36 plates provide unparalleled reliability and structural integrity in the demanding fields of maritime and ocean engineering.
Aatir Steel is a leading manufacturer, supplier and exporter of high-quality Carbon Steel, Alloy Steel, Mild Steel and Galvanized Steel products. Our extensive product range includes Pipes, Tubes, Flanges, Pipe Fittings, Forged Fittings, Sheets and Plates, catering to various industries in Cairo, Egypt.
